Resin Molds: The Complete Guide to Moulds for Resin

Pink coloured epoxy being poured into a tray, one of many resin molds used for casting

The mould you choose decides more about a resin project than most beginners expect. It sets the shape, the surface finish, how easily the piece releases, and even how much heat the resin can safely build while curing. Whether you are searching for resin molds for coasters and jewellery or a large form for a river table, the same principles apply: the right material, the right size, a proper seal and the right release method.

In our London workshop we use everything from small silicone moulds for test pours to large melamine and HDPE forms for table tops. This guide brings it all together: the main types of epoxy resin molds, how to choose sizes and depths, release agents, care and storage, and how to build your own mould when nothing off the shelf fits. Whether you call them moulds (UK) or molds (US), it is the same craft.

What are resin molds?

A resin mould is any container or form that holds liquid resin in shape until it cures. Good moulds have three things in common: the resin does not stick to them (or a release agent stops it sticking), they are watertight, and they are rigid or supported enough not to bulge under the weight of the liquid. Epoxy is a strong adhesive, so a mould that resin bonds to is effectively a permanent part of the piece.

Moulds fall into two broad groups:

  • Flexible moulds, mostly silicone, which you peel away from the cured piece. Ideal for small, detailed and repeatable shapes.
  • Rigid forms, made from HDPE, melamine-faced board, acrylic or polypropylene, which are taken apart or the piece is pushed out. Used for slabs, tables and large castings.

Types of resin moulds

Silicone molds for resin

Silicone is the most popular mould material for craft resin. Platinum-cure silicone gives a glossy finish where the mould surface is shiny, does not need a release agent for epoxy, and can be bent to free undercuts. Tin-cure silicone is cheaper and fine for prototypes but tends to wear out sooner. Shiny moulds give shiny pieces; matte moulds give a frosted surface that needs sanding and polishing or a top coat.

Typical uses: coasters, trays, jewellery, keyrings, spheres, bookends, small bowls and the kind of decorative pieces covered in our resin art guide.

HDPE and polypropylene forms

High-density polyethylene and polypropylene are low-surface-energy plastics that epoxy cannot grip well. Sheets of HDPE are screwed together into reusable rectangular forms for table tops, boards and slabs. They are rigid, can be reused many times, and release cleanly, though a silicone sealant bead is still needed at the joints.

Melamine board forms

Melamine-faced chipboard is the budget favourite for one-off table moulds. Epoxy will stick to it, so it must be covered with packing tape or sheathing tape, or coated with a release agent, and every seam sealed with silicone or hot glue. It is what many makers use for their first river table.

Acrylic and plastic moulds

Rigid plastic moulds (often PET or acrylic) give a very glossy finish and are cheap, but epoxy can bond to some plastics and they crack under heat. Always use a release agent and keep pours shallow.

Everyday and improvised moulds

Polypropylene food containers (look for the number 5 recycling mark), PE bags and silicone baking trays all work as improvised moulds. Avoid glass, metal and wood without a release barrier – resin bonds firmly to all three.

Mould type Release agent needed? Reusable? Best for
Platinum silicone No (for epoxy) Many times Detailed small pieces, coasters, jewellery
Tin-cure silicone Sometimes Fewer cycles Prototypes, cheap one-offs
HDPE / PP sheet Recommended Many times Table tops, boards, slabs
Taped melamine Tape or release agent A few times One-off tables and large castings
Rigid plastic (PET/acrylic) Yes Limited Shallow decorative pieces

Choosing the right mould for your resin

Match the mould to the resin type

Not all resins suit all moulds. Coating or doming epoxies are designed for thin layers, typically up to about 3–6 mm per pour, and will overheat in a deep mould. Casting and deep pour epoxy resins cure slowly so they can fill deep moulds in one go, typically 25–50 mm or more depending on the product and volume. UV resin only cures where light reaches, so it suits shallow, open silicone moulds rather than deep or opaque ones.

Size and depth

The deeper and larger the mould, the more heat builds inside the curing resin. That heat (an exotherm) can cause cracking, yellowing, bubbles or even soften a plastic mould. Always check the maximum pour depth on the resin you plan to use, and pour in layers if the mould is deeper than that.

Volume

To work out how much resin a rectangular mould needs, multiply length × width × depth in centimetres, then divide by 1,000 for litres. A 30 × 30 × 1 cm tray holds 0.9 litres. For round moulds use π × radius² × depth. For irregular silicone moulds, fill with water, pour into a measuring jug, then dry the mould thoroughly – water and epoxy don’t mix. Our how much epoxy do I need guide covers the maths for larger pours.

Surface finish

Glossy mould, glossy piece. If you want a clear finish straight from the mould, invest in high-gloss silicone or polished HDPE. Matte or scratched moulds will need sanding and polishing afterwards.

Release agents and how to use them

A release agent forms a barrier that stops epoxy bonding to the mould. Options include:

  • Spray mould release designed for resin and silicone.
  • Paste wax (several thin coats, buffed between each) on rigid forms.
  • PVA (polyvinyl alcohol) film release, often used over wax for difficult surfaces.
  • Packing or sheathing tape on melamine and wood.

Apply release thinly and evenly; pooled release can leave a dull or dimpled surface. On silicone moulds for epoxy, release agents are normally unnecessary but can extend mould life, especially with heat-generating castings.

How to use resin moulds step by step

  1. Check the mould is clean, dry and dust-free. Wipe silicone with a lint-free cloth or use tape to lift dust.
  2. Level it. Use a spirit level on your work surface. An unlevel mould gives a tapered piece.
  3. Seal seams on rigid forms with silicone sealant or hot glue and let it cure.
  4. Warm the resin to room temperature, typically 20–25°C, to reduce bubbles.
  5. Measure and mix precisely by weight or volume as specified. Our guide to how to pour epoxy resin covers mixing and pouring technique in detail.
  6. Add colour such as mica powder, alcohol inks or pigment pastes – see our guide on how to colour epoxy resin.
  7. Pour slowly from one corner or the lowest point to let air escape.
  8. Pop bubbles with a heat gun or torch on low, held well above the surface.
  9. Cover to keep dust off and leave to cure at stable temperature.
  10. Demould only after the time stated for full handling cure – often 24–72 hours for craft epoxy and longer for deep pour resins.

Moulds for resin tables and large castings

Table forms are where most mould problems happen, because the volumes are large and a leak can empty litres of resin onto the floor. A typical table form is a flat base of melamine or HDPE with side walls screwed on, every internal edge sealed, and the inside taped or coated with release. The live-edge timber is clamped or weighted down so it doesn’t float. You’ll find the full process in our guides to how to make a resin table.

Tips for table moulds:

  • Build the form a little larger than your finished top so you can trim the edges.
  • Seal with silicone and test with water if you are unsure, then dry it completely.
  • Use a slow-curing deep pour resin and respect its maximum layer depth.
  • Keep the workshop at a steady temperature during curing.

Making your own resin moulds

When you need a shape you can’t buy, make a silicone mould from an original (the master):

  1. Fix the master to a flat base inside a mould box made of plastic, foam board or Lego bricks.
  2. Seal any gaps and spray a light release if the master is porous.
  3. Mix two-part silicone rubber accurately and pour it in a thin stream into the lowest corner, letting it rise around the master.
  4. Ensure at least 5–10 mm of silicone covers the highest point and surrounds the sides.
  5. Cure as directed, typically 4–24 hours, then demould and remove the master.

For moulds with undercuts, a two-part mould with registration keys lets you remove the piece cleanly. Some makers also use preserved items in resin – our guide to preserving flowers in resin includes notes on choosing moulds for botanicals.

Caring for your moulds

  • Peel pieces out gently; do not stab silicone with sharp tools.
  • Wash silicone in warm soapy water and dry thoroughly, or simply peel off residue once cured.
  • Store flat and out of sunlight, without heavy objects stacked on top to avoid distortion.
  • Keep resin moulds separate from food use; once used for resin, a mould should not go back in the kitchen.
  • Expect silicone to dull over time, particularly with hot, deep pours. A dull mould can still be used for pieces you plan to sand.

Common mould problems and fixes

Problem Likely cause Fix
Resin stuck to mould No release, incompatible plastic Use silicone or HDPE; apply release
Leaks Unsealed seams Seal with silicone, test before pouring
Sticky surface where it touched the mould Moisture in mould, inhibition with some silicones Dry mould fully; test resin with new moulds
Cracking or yellowing Pour too deep for the resin Use deep pour resin or pour in layers
Bubbles on the face Air trapped in details Brush a thin first layer into details before filling

For more on the process behind mould work, Wikipedia’s articles on resin casting and silicone rubber explain how liquid resins are cast into flexible moulds and why silicone releases epoxy so cleanly.

Watch it being made

Watch our first light-up resin table being made in the workshop, with dragons and creatures appearing in the resin art, and the colours, pours and finishing shown step by step.

Resin Art Dragons and creatures in resin art table My First Light-Up Resin Table. More builds on the Go Bespoke YouTube channel.

Frequently asked questions

What molds can you use for epoxy resin?

Silicone, HDPE, polypropylene and taped or release-coated melamine are the most reliable. Avoid untreated glass, metal and wood, which epoxy bonds to strongly.

Do you need release agent for silicone resin molds?

Not usually for epoxy in platinum-cure silicone, but a light spray can extend mould life and help with very detailed or deep castings.

What is the best material for a resin mould?

For small pieces, high-gloss platinum silicone. For tables and slabs, reusable HDPE or taped melamine forms. Choose based on size, finish and how many times you will reuse it.

How long should resin stay in the mould?

Most craft epoxies can be demoulded after 24–48 hours, while deep pour resins often need 72 hours or more. Check the handling time for your specific resin and room temperature.

Can I make my own resin moulds?

Yes. Two-part silicone rubber poured around a master object in a simple mould box gives a custom, reusable mould. For flat shapes, an HDPE or taped melamine form works well.

Are resin molds and resin moulds the same thing?

Yes – molds is the US spelling and moulds the UK spelling. Products and techniques are identical.

Start pouring

If you are new to resin, read our epoxy resin for beginners guide, start with a small silicone mould and build up to larger castings. For more inspiration, browse epoxy resin art ideas or watch our builds on YouTube. If you would rather have a large resin table made for you, get in touch about a bespoke commission.
